 Plastic Junction Boxes

Plastic Junction Boxes Economical, Pre-configured, NEMA 4X Plastic Junction / Splice Boxes

Series: PJB

Features

     Rugged, PVC Industrial Plastic

     Weatherproof, UL Listed, NEMA 4X Rating

     Gasketed Lid & Built-in Mounting Feet

     Models in 4 Different Sizes

     Available with Cables Glands & Hubs


Applications
  • Sump Pump Basins, Holding Tanks
  • Holding & Sewage Tanks
  • Pump Control & Alarm Wiring
  • PV System Combiner
  • Outdoor Lighting
  • Industrial Controls
Description

Our PJB Series of Economical, Pre-configured Plastic Junction Boxes offer all the corrosion resistance and physical properties you need for applications ranging from the industrial floor to outdoor installation. Features include a NEMA 4X rating, built-in mounting feet and a gasketed cover. Models are available with waterproof cable glands and conduit hubs.

General Specifications
Enclosure Rating: NEMA 4X, UL Listed
Enclosure Material: Gray(PVC) Plastic
Operating Temperature: -40 to 175 ºF (-40 to 80 ºC)
Dimensions: See Model Chart
Installation: Wall, Roof or Pole Mounted, For Indoor or Outdoor Use

Available Models
Model Number Description Picture
PJB-442 4 X 4 X 2" Junction Box Only Plastic Junction Boxes
PJB-442-2CG 4 X 4 X 2" Junction Box with 2 Cable Glands Plastic Junction Boxes
PJB-444 4 X 4 X 4" Junction Box Only Plastic Junction Boxes
PJB-442-3CG-15H 4 X 4 X 2" Junction Box with 3 Cable Glands
and 1.5" Hub 		Plastic Junction Boxes
PJB-442-4CG-15H 4 X 4 X 2" Junction Box with 4 Cable Glands
and 1.5" Hub 		Plastic Junction Boxes
PJB-664 6 X 6 X 4" Junction Box Only Plastic Junction Boxes
PJB-664-3CG 6 X 6 X 4" Junction Box with 3 Cable Glands Plastic Junction Boxes
PJB-664-3CG-15H 6 X 6 X 4" Junction Box with 3 Cable Glands
and 1.5" Hub 		Plastic Junction Boxes
PJB-664-3CG-2H 6 X 6 X 4" Junction Box with 3 Cable Glands
and 2" Hub 		Plastic Junction Boxes
PJB-664-4CG 6 X 6 X 4" Junction Box with 4 Cable Glands Plastic Junction Boxes
PJB-664-4CG-15H 6 X 6 X 4" Junction Box with 4 Cable Glands and 1.5" Hub Plastic Junction Boxes
PJB-664-4CG-2H 6 X 6 X 4" Junction Box with 4 Cable Glands and 2" Hub Plastic Junction Boxes
PJB-664-5CG 6 X 6 X 4" Junction Box with 5 Cable Glands Plastic Junction Boxes
PJB-664-5CG-2H 6 X 6 X 4" Junction Box with 5 Cable Glands and 2" Hub Plastic Junction Boxes
PJB-884 8 X 8 X 4" Junction Box Only Plastic Junction Boxes
PJB-884-4CG-2H 8 X 8 X 4" Junction Box with 4 Cable Glands and 2" Hub Plastic Junction Boxes
PJB-884-6CG-2H 8 X 8 X 4" Junction Box with 6 Cable Glands and 2" Hub Plastic Junction Boxes
