Universal Alarm Box
|

|
|
Economical Operator Station Boxes with Switches, Buzzers & LED Indicators
Series: SBP
Features

Available with LED Indicators, Buzzers & Switches

Single or Dual Position Versions

Fits All Standard Plastic or Metal 2-gang Boxes

White or Ivory Plastic, Painted or Stainless Steel

12V DC, 24V DC or 120V AC Input

Rotary, Push-button or Mushroom Head Switches

Keyed or Non-Keyed Switches Available
Applications
|
- Operator Station Indicators and Controls
- Level, Flow, Humidity, Pressure Temperature Alarms
- Indication or Control for Office or Factory
|
Description
The SBP Series of economical operator station wall plates provide a low cost solution for adding
switches, LED Indicators and Audible Buzzers to any factory or office application. Plates are available
in white and ivory plastic, or painted and brushed stainless steel. Multi-color Buzzers and LED Indicator
operate on 12V DC, 24V DC or 120V AC. Available switches include Keyed and Non-keyed Rotary,
Momentary Push-button and 40mm Mushroom Head for rapid shutdown applications.
|
|
Specifications
|
Plates Available:
|
White or Ivory Plastic, Painted or Stainless Steel
|
Plate Material:
|
Plastic or Metal
|
Audible/Visual Alarm:
|
Red, Green or Yellow, 80db
|
LED Indicators:
|
Red, Green, Yellow, Blue, White
|
Switch Types:
|
Rotary, Push-button or Rapid Shutdown
|
Switch Ratings:
|
See switch type model chart
|
Operating Power:
|
12V DC, 24V DC or 120V AC
|
Max Temperature:
|
-40 to175 ºF (-40 to 80 ºC)
|
Installation:
|
For Indoor Use Only
|
Mounting:
|
Fits All Standard 2-Gang Boxes
|
|
Available Models
|
Models
|
Data Sheet Link (pdf)
|
See Data Sheet for Full Model List
|
Data Sheet
|
|
Note: Continued product improvements make specifications subject to change without notice.
|
|
